Model |
DQZR180Z |
DQZR200Z |
DQZR250Z |
|
Maximum Hook Load |
1800kN |
2000kN |
2500kN |
|
Rated Voltage of Main Motor |
380VAC |
600VAC |
600VAC |
|
Mud Passage |
76mm |
76mm |
76mm |
|
Rated Pressure of Central Pipe Bore |
35MPa |
35MPa |
52MPa |
|
Operating Temperature |
-40℃～55℃ |
-40℃～55℃ |
-40℃～55℃ |
|
Spindle Speed Range |
0-220r/min |
0-220r/min |
0-220r/min |
|
Rated Torque |
40kN·m |
55kN·m |
66kN·m |
