Technical Parameters |
ZJ30DBT/1850 |
ZJ40DBT/2700 |
|
Max. Hook Load |
1800 |
2500 |
|
Drilling Depth (114 D P) |
1600-3000 |
2500-4500 |
|
Drawwork motor power (KW) |
800 |
1200 |
|
Max.Hook Lifting Speed |
0.2-1.3m/s |
0.2-1.3m/s |
|
Rotary table motor power (KW) |
400 |
400 |
|
Number of Motors |
1 |
1 |
|
Derrick Structure Design |
Telescopic-two - section type |
|
|
Derrick Height (m) |
38 |
39 |
|
Drill Floor Height (m) |
6 |
7.2 |
|
Transmission Form |
Hydraulic-Mechanical type |
|
|
Max. Tension of Fast Line (KN) |
225 |
330 |
|
Wire Rope Diameter |
ф29 |
ф32 |
|
Traveling Block and Hook Model |
YG180 |
YG250 |
|
Swivel Model |
SL170/SL225-Ⅱ |
SL250 |
|
Rotary Table Model |
ZP205/ZP275 |
ZP205/ZP275 |
|
Transport Dimension (m) |
17*3*3.1 |
17.7*3.3*3.5 |
|
Weight (kg) |
45000 |
47900 |
